VDCora VERSION 2.19.1

PRODUCTIVITY TOOLS FOR AUTODESK REVIT

Less repetition.
More model work.

VDCora brings practical modeling, coordination, and documentation commands into Revit—built around the tasks that slow real projects down.

Download VDCora Explore the tools
VDCORAOne toolkit. Many workflows.
01Model coordination
02MEP utilities
03Documentation
04Model generation
BUILT FOR REVIT PROJECT TEAMSVD / 26
PRECISION AT THE CORE OF EVERY MODEL.EXPLORE BELOW ↓

THE IDEA

Keep the work in the model.

VDCora turns repeatable Revit tasks into focused commands. Many tools work with linked RVT or IFC models, report what they changed or skipped, and give you a preview when scope matters.

THE TOOLKIT / V2.19.1

Tools for the work
between milestones.

Choose the command that fits the task. Each tool lives in a purpose-built VDCora ribbon panel inside Revit.

01 / MEP

Duct & pipe

01

Fabrication to Pipe

Rebuild round fabrication pipework from a host or linked model as native Revit Pipe. Follow a connected run or choose individual parts; preview the scope and review any fitting gaps.

02

Set Duct Elevation

Set selected straight ducts by bottom, center, or top elevation relative to their reference level.

03

Flat Transition

Flatten the top or bottom of selected rectangular duct transitions while checking connected geometry.

02 / COORDINATION

Links & datums

04

Align Links

Move a linked RVT, IFC, or CAD instance onto a reference link with a preview of the exact position and rotation change.

05

Adjust Extents

Move the displayed ends of selected grids and levels without pulling other aligned datums along.

06

Grid/Level Bubbles

Show or hide datum heads at either end of multiple selected grids and levels in one pass.

03 / DOCUMENTATION

Views & sheets

07

Match Sheet Position

Align corresponding views across sheets using model-to-sheet coordinates, even when their crops differ.

08

Ceiling Grid

Place your grid family along ACT ceiling lines, including ceilings in linked architectural models.

04 / MODELING & FIELD

From source to model

09

Model Fireproofing

Create traceable Revit geometry around structural members from the host or a loaded link.

10

Model King Studs

Generate full-height king studs beside selected door openings without a separate stud family.

11

Board & Batten

Lay out vertical batten strips across selected straight walls with facade-wide spacing controls.

12

Laser Scan Plan

Plan Trimble X7 stations against model geometry and create a Revit view with estimated sightline coverage.

13

CMU Rebar

Create schematic vertical bars from host or linked CMU walls, with selectable wall scope, spacing layouts, and a preview before placement.

14

Existing Terrain

Build existing-ground Revit terrain from a bounded USGS 3DEP sample or a local XYZ point file, with map-based site selection.

GETTING STARTED

Ready when Revit is.

The VDCora installer carries the add-in builds for supported Revit versions and installs to your Windows user profile. Administrator rights are not required.

CURRENT RELEASE V2.19.1

Download VDCoraSetup.exe

Windows may show a SmartScreen prompt for this unsigned installer. Follow your organization's software policy.

  1. 01
    Close Revit

    Exit all open Revit sessions before installing.

  2. 02
    Run VDCoraSetup.exe

    Open the downloaded installer.

  3. 03
    Choose your Revit versions

    Tick the versions you use, then select Install.

  4. 04
    Open the VDCora tab

    Restart Revit and find the new ribbon tab.
